KoolMore CIM198 - SPECIFICATIONS; DIMENSIONS;CONNECTIONS; Rating

SPECIFICATIONS
1) DIM ENSIONS/CONNECTIONS
2) Rating
POWER SUPPLY VOLTAGE 1Phase, 110-120/60Hz
MODEL CIM198 CIM265
CLIMATE CLASS
10-40℃ 10-40℃
ELECTRICAL PROTECTION CLASS I I
ICE MAKING RATING (Amps) 4.4 Amp 7.5Amp
ICE HARVEST RATING (Amps) 5.0 Amp 7.8Amp
ICE MAKING CAPACITY (KG/24H) 90kg/24Hour
*
120kg/24Hour
*
REFRIGERANT CHARGE R290 3.67Oz / 104g R290 3.35Oz / 95g
NET WEIGHT(KG) 77 lbs 90 lbs
VESICANT C
5
H
10
UNIT DIMENSIONS(W X D X H) (mm) 556 x 435 x 832
CONNECTION POWER CORD----18AWG
WATER SUPPLY----6.35mm diamete
DRAIN----Φ16
SYLPHON BELLOWSS(RE A R)
WATER CONSUMPTION(L/24H) 100L 130L
MAX ICE STORAGE CAPACITY(KG) 20Kg
ACCESSORIES SHOVEL, INSTALLATION KITS
RUNNING CONDITIONS ROOM TEMP 50-110 Fahrenheit
WATER SUPPLY TEMP 41-95 Fahrenheit
WATER SUPPLY PRESSURE 0.04-0.6 MPa
NOTE *: TESTED AT 70 Fahrenheit ROOM TEMPERATURE AND 50 Fahrenheit WATER TEMPERATURE.
Water
Inlet Port
Water
Drainage Port
5
