89
8. Appendix
Restoring the factory settings
The pattern and song data with which the EMX-1 was shipped
from the factory is called the “preload data.” You can load
this preload data to restore the EMX-1 to its factory-set
condition.
When you do this, the patterns or songs you created will
be erased, and replaced by the preload data. If you want
to keep the patterns or songs you created, you must save
them to SmartMedia first.
1. While simultaneously holding down the Transpose
key (Solo key) and the Write key, turn on the power.
2. The display will indicate “Preload,” and the PLAY/
PAUSE key will blink.
3. If you want to load the preload data, press the blink-
ing PLAY/PAUSE key.
It will take approximately 30 seconds for the data
to be loaded.
If you decide to cancel before executing, press the
STOP/CANCEL key.
When loading is completed the EMX-1 will be ini-
tialized, and after a few seconds will enter Pattern
mode with the display indicating pattern number
“A01.”
Never turn off the power while data is being loaded.
Doing so may destroy the data.
Specifications
Number of parts: 16 parts (5 synth parts, 9 drum parts, 1 synth
accent part, 1 drum accent part)
Memory capacity: 256 patterns, 64 songs
Effects: Three processors x 16 types
Sequences: Maximum of 128 steps per part.
Motion sequences: Total of 24 freely assignable sequences totaling
Song: Maximum of 256 patterns per song.
Maximum 20,000 events for event recording.
Connectors**:
PHONES
Phone jack: stereo
Maximum output level: 16 mW/33-ohms or
more / TUBE GAIN = min
Output impedance: 33 ohms
OUTPUT (L/MONO, R)
Phone jacks: mono x 2
Maximum output level: 0 dBu or more / TUBE
GAIN = min
Output impedance: 220-ohm (110-ohm at
MONO)
Load impedance: 10 k-ohms or more
INDV.OUT (3, 4)
Phone jacks: mono x 2
Maximum output level: +7 dBu or more
Output impedance: 220-ohm
Load impedance: 10 k-ohms or more
INPUT (AUDIO IN)
Phone jack: mono (unbalanced)
Input impedance: 10 k-ohms (at LINE) /
910-ohm (at MIC)
Maximum input level
(at LINE): -20dBu/ AUDIO IN LEVEL = max
(at MIC): -52 dBu / AUDIO IN LEVEL = max
Source impedance: 600 ohms
MIDI (IN, OUT, THRU)
5-pin DIN
SmartMedia
TM
: 4–128 MB, 3V (3.3V)
Vacuum tube: 12AX7/ECC83 x 2
Power supply: AC9V (included AC/AC power supply)
Power consumption
: 23 W
Dimensions: 358 (W) x 256 (D) x 62 (H) mm (including the
rubber feet)
Weight: 3.1 kg
** Analog specifications such as output levels are measured
at the point where the vacuum tubes have stabilized af-
ter power-on. These values may change due to variations
in the environmental temperature.
