Korg M50 User Manual

2
Installation
Installation in Windows XP / Windows Vista
To install the M50 Editor and the M50 Plug-In Editor into Windows XP or Windows Vista,
proceed as follows.
If you want to connect the M50 to your computer via USB and use the M50 Editor and the
M50 Plug-In Editor, you must install the Korg USB-MIDI Driver. (Refer to the Installation
Guide for details on how to install the Korg USB-MIDI Driver.)
1
Insert the included CD-ROM into your computer’s CD-ROM drive.
Normally the “M50 Application Installer” will start up automatically.
If your computer is set so the installer does not run automatically, double-click
“KorgSetup.exe” on the CD-ROM.
2
From the list, select the applications that you want to install, and click [Install].
The applications you selected will begin the installation process.
3
4
Follow the on-screen directions to install the desired applications, such as M50 Editor.
When you’ve finished installing all the selected software, close the installer.
Installing the Korg USB-MIDI Driver
Refer to the Installation Guide for details on how to install the Korg USB-MIDI Driver.

Korg M50 Specifications

General

Polyphony	80 voices
Sound Engine	EDS (Enhanced Definition Synthesis)
Outputs	L/MONO, R, Headphones
MIDI	In, Out, Thru
Storage	SD card slot
Keyboard	61 keys, 73 keys, or 88 keys
Effects	2 master effects
Sequencer	16-track, 128 songs
Display	TouchView graphical interface
Arpeggiator	2 arpeggiators
Presets	608 Programs, 384 Combinations
Controllers	Joystick
Key Action	M50-61/73: Semi-weighted, M50-88: RH3 (Real Weighted Hammer Action 3)
Connectivity	USB
