Korg nanoPad2 User Manual

4
Gate arpeggiator
Gate arpeggiator
When the Touch Scale mode is “off”
The gate arpeggiator will apply to the trigger pads only while you’re touching the X-Y pad.
Velocity
Gate speed
X-axis: Gate speed
This specifies the interval at which the notes are spaced.
Notes will be sounded at intervals of 1/2 (half-note) on the left edge of the pad, and at intervals of 1/48 (32nd note triplet) on the right edge.
Y-axis: Velocity
This specifies the velocity of the note messages that are transmitted by the gate arpeggiator.
Note messages are transmitted with a velocity of 1 on the bottom edge of the pad, and a velocity of 127 on the top edge.

Korg nanoPad2 Specifications

General

Type	Effects processor
Proper use	Concert/Studio
Product color	White
Cables included	USB

Weight and Dimensions

Depth	83 mm
Width	325 mm
Height	16 mm
Weight	285 g
