34|
SCENE 1 (Keyboard/Pads) SCENE 2 (Accompaniment)
MIDI IN Channel Sound/Track MIDI IN Channel Sound/Track
Ch01 Upper 1 Ch09 Drum
Ch02 Upper 2 Ch10 Percussion
Ch03 Upper 3 Ch11 Bass
Ch04 — Ch12 Acc 1
Ch05 — Ch13 Acc 2
Ch06 — Ch14 Acc 3
Ch07 — Ch15 Acc 4
Ch08 — Ch16 Acc 5
Play
4 When you want to send messages to the Pa-Series instrument, select the
Scene of the external controller corresponding to the group of Sounds to be
controlled, and use the controls on the external controler.
If you like, you can create your own set of sounds to be controlled, by mixing
and matching the different MIDI channels. This is especially useful when us-
ing a controller with no memorizable Scenes.
