Installing a microSD card |161
Feature Pa1000
Sequencer Quick Record (Backing Sequence), Multitrack and Step Record
functions
Full-featured sequencer, 16 tracks, Up to 200,000 events, SMF
(MID) native format
SongBook Fully programmable music database, based on Styles, MIDI
Songs (MID and KAR les), MP3 Songs, with automatic selection
of Style Play and Song Play modes
User denable Set Lists, with Entries selectable from the control
panel
Filtering and sorting options
Compatibility Pa-Series models: Styles, Performances/Keyboard Sets,
Programs/Sounds, Songs, SongBook Entries, Pads
‘i-Series’ models: Styles
Pads Four Assignable Pads + Stop buttons
Pad Record function
General Controls Master Volume; Fade In/Out; Keyboard-Acc/Song Balance;
Ensemble; Octave Transpose; Master Transpose; Quarter Tone
and Arabic Scale memorized inside Keyboard Sets; Joystick;
Audio In Volume; Mic FX Level; Harmony/Double On/Off; Mic/
Guitar Preset; Audio In Mute; 2 Assignable Knobs; 3 Assignable
Switches; Tempo +/-; Tempo Lock; Metronome On/Off; Dial;
Search; Shift; Chord Scan (Lower, Upper); Split; Track Select;
Record
Scale Controls Virtual Quarter Tone SubScale Keypad, 4 x Scale Presets
Control Inputs Damper pedal (supports half-pedaling with the optional DS-1H
pedal)
Assignable pedal/switch
Audio Inputs Line (Left/Right): 1/4” jacks, +20dBm, 12 kOhm
Mic/Guitar (Left): 1/4” jack, with Gain control (0 ~ +40dB)
12 kOhm (Mic) / 500 kOhm (Guitar)
Audio Outputs Left/Right, 1/4” jack, +21dBm, 0.003% THD+N@+18dBm
Headphone output (1/4” jack), 16-200 Ohms (50 Ohms suggest-
ed)
Speaker System Amplication: 2 x 33 W
Speakers: 2 x 100 mm woofers in bass reex box, 2 x 25 mm
dome tweeters
MIDI IN, OUT standard MIDI connectors
USB to MIDI using the USB ports
Eight user denable MIDI Setups
