Pa2Xpro PART LIST
PART LIST CPU BOARD GRA1002100
CODE DESCRIPTION REFERENCE Q.TY
CIN0002075 DSP TG01 MB87M4080PB-G (KORG INC) 1
CIN0002076 USB DEVICE TRANCEIVER ISP1105BS (PHILIPS) 1
CIN0002077 INT. SYSTEM PROCESSOR MC9328MX1VM20 1
CIN0003043 IC.SDRAM 16MX16 MT48LC16M16A2TG-75 SOP54 6
CIN0004005 RES.GEN.3,3V ETC811SUC 1
CIN0010031 IC BUFFER, SN74LVC541APWR, TSSOP20 3
CIN0010032 8BIT BID.BUF. W TRIS.SN74LVC245APWR, TSSOP20 2
CIN0010033 QUAD 2 IN OR GATE, SN74LVC32APWR, TSSOP14 4
CIN0010034 HEX SCHMITT TRIG. INV. SN74LV14APWR, TSSOP14 1
CIN0010035 HEX.UNB. INV. SN74AHCU04PW, TSSOP14 1
CIN0010036 DUAL D- FLIP FLOP.SN74LVC74APWR, TSSOP14 1
CIN0010037 SDRAM, 64MBIT, 16BIT, K4S641632K-UC75, SSOP54 1
CIN0010039 SINGLE 2 IN AND GATE, 74LVC1G08DCK, DCK5 2
CON0001128 26X1.27 VER. PICOFLEX SMD 90814-0026 1
CON0001129 SODIMM CONN. 144PIN SIDE ENTRY 54698-1440 1
CON0010014 CONN. M. OR. PTH, 1 FILE, 3 VIE, 2,5MM, S3BEH, JST 1
CON0010040 STRIP F. VER. SMD, 2 F,44V,2MM, H4.6,CB74442M100 3
DIX0006003 SMD DIODE RLS-4148 2
QUA0006004 X-CRYSTAL SMD HCM49 16MHZ 1
QUA0006005 X-CRYSTAL SMD HCM49 24.576MHZ 1
QUA0006012 X-CRYSTAL SMD 32.768KHZ SMD PKG CM200S 1
TRS0002015 ADJ OUT 1.5° LD1086D2T ST/LM1086CSX-ADJ NAT. 1
PART LIST 128MBYTE SDRAM EXB SODIMM 144 GRA1002101
CODE DESCRIPTION REFERENCE Q.TY
CIN0003043 IC.SDRAM 16MX16 MT48LC16M16A2TG-75 SOP54 4
