Korg Pa2Xpro - Plastic Components List

Pa2Xpro PART LIST
PART LIST PLASTIC COMPONENTS
CODE DESCRIPTION REFERENCE Q.TY
PLA0001046 SMALL CABLE TIE LC UC1 KG 8
PLA0001047 BIG CABLE TIE LC UC1 LCD 11
PLA0001062 CABLE HOLDER PAN-TY LC 1
PLA0001094 CST SPACER 6MM SRS4-04-01 KG 2
PLA0001110 MUSIC REST SUPPORT LC 2
PLA0001130 FLAT CABLE HOLDER CFCC-8-04° LC 1
PLA0001132 DISPLAY BUTTONS LCD 1
PLA0001133 DIAL SUPPORT UC2 1
PLA0001134 UP BUTTON UC2 1
PLA0001135 DOWN BUTTON UC2 1
PLA0001136 DIAL KNOB D2 1
PLA0001137 BUTTON SUPPORT 17MM UC2 59
PLA0001138 BUTTONM SUPPORT 19MM UC2 27
PLA0001139 BUTTON 17MM WITH LED UC2 18
PLA0001140 BUTTON 17MM WITHOUT LED UC2 16
PLA0001141 BUTTON 19MM WITH LED UC2 15
PLA0001142 BUTTON 19MM WITHOUT LED UC2 7
PLA0001143 SPACER 4.2 X 3.7 X 8 X 2.6 UC2 20
PLA0001144 LED PROTECTION UC2 13
PLA0001146 SLIDER KNOB D2 10
PLA0001147 SLIDER FRAME 30MM UC2 12
PLA0001148 RED BUTTON 19MM WITH LED UC2 1
PLA0001157 MAIN SWITCH LC MG 1
PLA0001163 RUBBER FEET Ø20 H10 LC 5
PLA0010035 BUTTON 17MM WITH LED ( NOVODUR 700700) UC2 24
PLA0010036 BUTTON 17MM WITHOUT LED (NOVODUR 700700) UC2 3
PLA0010037 BUTTON 19MM WITH LED (NOVODUR 700700) UC2 4
PLA0010039 SLIDER KNOB ( NOVODUR 700700) D2 2
PLA0010065 MOTOR CONTROL BUTTON UC2 1
PLA0010066 MOTOR UNLOCK BUTTON LCD 1
PLA0010067 ENDLESS SCREW RACK LCD 1
PLA0010068 DISPLAY RACK LCD 2
PLA0010069 RACK LCD 1
PLA0010070 DISPLAY POTENTIOMETER RACK LCD 1
PLA0010073 ENDLESS SCREW SUPPORT LCD 1
PLA0010075 SHAFT SUPPORT LCD 3
PLA0010076 SQUARE BELT PINION LCD 1
PLA0010077 SQUARE BELT PULLEY LCD 1
PLA0010078 ENDLESS SCREW REAR SUPPORT LCD 1
PLA0010079 SQUARE BELT 2X2 D.42 COD. 9000420 LCD 1
PLA0010081 ROUGH DISPLAY COVER LCD 1
PLA0010082 ROUGH DUSPLAY SUPPORT LCD 1
PLA0010083 ROUGH USB FRAME UC1 1
PLA0010084 VIDEO OUTPUT PLUG LC 1
PLAL001009 JOYSTICK SUPPORT UC1 1
PLAL001012 DISPLAY PANEL LCD 1
D1 = Disassembly 1 D2 = Disassembly 2 LC = Lower Case UC1 = Upper Case 1 UC2 = Upper Case 2 KG = Keyboard Group
GRF = GRF0001006 HDD = HDD Group HG = Headphone Group DG = Dial Group MG = Main filter Group RLS = Right-left Side Group
