Pa2Xpro PART LIST
PART LIST HARNESSES
CODE DESCRIPTION REFERENCE Q.TY
CAV0010001 FLAT CABLE HDD IF OPT0001008 LC 1
CAV0010027 FLAT CABLE MB/OUT BOARD LC GRF 1
CAV0010028 FLAT CABLE MB/RX PANEL D2 UC1 GRF 1
CAV0010029 FLAT CABLE RX/LX PANEL UC1 1
CAV0010030 FLAT CABLE MB/VIDEO BOARD LC GRF 1
CAV0010031 FLAT CABLE CPU/LCD IF D2 LC 1
CAV0010032 FLAT CABLE RX PANEL/DIAL DG 1
CAV0010033 FLAT CABLE LX PANEL/SOUND CTRL BOARD UC1 1
CAV0010034 FLAT CABLE MB/KEYBOARD IF KG 1
CAV0010035 FLAT CABLE KEYB IF/KEYB LOWER KG 1
CAV0010036 FLAT CABLE KEYB IF/KEYB UPPER KG 1
CAV0010037 HARNESS MB/HDD IF LC 1
CAV0010038 HARNESS MB/FRONT USB D2 UC1 1
CAV0010039 HARNESS MOTOR IF/MB LC 1
CAV0010041 HARNESS SPDIF LC GRF 1
CAV0010042 HARNESS HEADPHONE LC 1
CAV0010043 HARNESS RX PANEL/LCD PANEL LCD 1
CAV0010044 FCC CAB. 4VIE, 1MM KONTEK GK0200-04223-4CCFF LCD 1
CAV0010045 HARNESS MOTOR/POT/SWITCH UC1 1
CAV0010046 FLAT CABLE MB/MP3 BOARD LC 1
RIL0001040 MAIN CABLE 1
RIL0001066 AWG HARNESS L 130 EC100 -PA80-PA60 KG 1
RIL0001281 HARNESS JOYSTICK UC1 1
RIL0010012 HARNESS PRIMARY LC MG 1
RIL0010016 HARNESS SUPPLY/AMPLIF LC 1
PART LIST HARNESS SUPPLY/AMPLIF RIL0010016
CODE DESCRIPTION REFERENCE Q.TY
BOB0001001 FERRITE RT25-150-120-K5B 1
PLA0001062 FASCETTA PICCOLA FCV-100 PAN TY 1
D1 = Disassembly 1 D2 = Disassembly 2 LC = Lower Case UC1 = Upper Case 1 UC2 = Upper Case 2 KG = Keyboard Group
GRF = GRF0001006 HDD = HDD Group HG = Headphone Group DG = Dial Group MG = Main filter Group RLS = Right-left Side Group
