Pa2Xpro PART LIST
PART LIST MOTOR INTERFACE BOARD GRA0002139
CODE DESCRIPTION REFERENCE Q.TY
CIN0002047 I.C.HEX INV 74AHC04D 1
CIN0002063 I.C.QUAD 2-IMPUT GATE.SN74AHC08 D SMD 1
CIN0010049 PSOC UC CYPRESS CY8C24123A-24SXI 1
CON0010022 CONN. M. V. PTH, 1 FILE, 6V, 3,96MM, B6P-VH-K, JST 2
CON0010035 CONN. M. V. PTH, 1 FILE, 7V, 2,5MM, B7B-EH-A, JST 1
DIX0006004 SMD DIODE SHOTTLY RB051L-40TE25 4
TRS0010009 COMP. P/N MOSFET 30V/-30V 7°/-5° KMB7D0NP30QA 2
PART LIST LCD INTERFACE GRA0002140
CODE DESCRIPTION REFERENCE Q.TY
BOB0005001 BOBINA VK200 2,0 SPIRE 1
CIN0001004 INT.LMC662CN OP.RAIL TR. 1
CON0001078 CONN.BLK PICOFLEX 26 VIE 1.27 1
CON0001099 CONN. HOR. FFC 16V 1MM (52043-1610) 1
CON0001100 CONN. HOR. FFC 4V 1MM (52043-0410) 1
CON0010066 CONN. HOR. PTH 1F 4V 2.5MM JAE IL-G4P-S3L2-SA 1
TRA0005001 LCD INVERTER DC-AC 4,5W 10° 1
PART LIST MOTOR HARNESS BOARD GRA0002141
CODE DESCRIPTION REFERENCE Q.TY
CON0010014 CONN. M. OR. PTH, 1 FILE, 3 V, 2,5MM, S3BEH, JST 1
FDD0010003 MOTORE QJT-370-AH, 6V, 6150RPM 1
PART LIST LCD HARNESS BOARD GRA0002142
CODE DESCRIPTION REFERENCE Q.TY
CON0010011 MALE CONN. HOR. PTH 1 FILE 4V 2,5MM S4BEH JST 1
POT0010002 POT.ROT.OR.10KBX 1, RV110-F-40E1-175A-B10K 1
PART LIST FRONT USB CONNECTOR BOARD GRA1002114
CODE DESCRIPTION REFERENCE Q.TY
CON0010009 PRESA USB TYPE A, 1
CON0010018 MALE CONN. HOR. PTH 1 FILE 5V 2,5MM S5BEH JST 1
RIL0001165 CONNESSIONE MASSA L=100 CUFFIA EC120-320 1
D1 = Disassembly 1 D2 = Disassembly 2 LC = Lower Case UC1 = Upper Case 1 UC2 = Upper Case 2 KG = Keyboard Group
GRF = GRF0001006 HDD = HDD Group HG = Headphone Group DG = Dial Group MG = Main filter Group RLS = Right-left Side Group
