Pa2Xpro PART LIST
PART LIST LCD PANEL BOARD GRA0002133
CODE DESCRIPTION REFERENCE Q.TY
CON0001087 CONN.MASCH.6 VIE PH20W6R ORIZ. 1
INT0001008 TACT SWITCH 8
PART LIST MAIN FILTER GRA0002134
CODE DESCRIPTION REFERENCE Q.TY
BOB0001001 FERRITE RT25-150-120-K5B 1
BOB0005001 BOB. VK200 2,0 SPIRE 4
CON0010019 CONN. M. V. PTH, 1 FILE, 3V, 3,96MM, B3P-VH-K, JST 1
INT0001012 MAIN SWITCH SS-160-7-A 1
INT0001013 F FLAT EAR PLUG 1
PLA0001057 NYLON RING N16B RICHCO 1
RIL0001217 AWG CABLE 1
VTA0001006 SCREW 3MX14TC 1
VTA0001023 M3 SELFLOCKING NUT 1
VTA0001048 WASHER 3X9X0.8 1
PART LIST TOUCH PANEL INTERFACE GRA0002135
CODE DESCRIPTION REFERENCE Q.TY
CON0010060 CONN. F. HOR. SMD 1 FILE 4 V. 1MM 04FMS-10SP-TF 2
PART LIST SOUND CONTROL PANEL GRA0002136
CODE DESCRIPTION REFERENCE Q.TY
CON0010065 CONN. M. VER. PTH, 2 FILE, 6 V, 1.27MM MICS 06 1
INT0001008 TACT SWITCH 2
PART LIST ROTARY ENCODER GRA0002137
CODE DESCRIPTION REFERENCE Q.TY
CON0010065 CONN. M. VER. PTH, 2 FILE, 6 V, 1.27MM MICS 06 1
INT0001008 TACT SWITCH 2
INT0001015 ENCODER STEC12E07 1
PART LIST HEADPHONE BOARD GRA0002138
CODE DESCRIPTION REFERENCE Q.TY
BOB0005001 BOB. VK200 2,0 SPIRE 2
CON0010015 CONN. M. VER. PTH 1 FILE 4V 2,5MM B4B-EH-A JST 1
CON0010058 6.3MM STEREO JACK NRJ6HH 1
D1 = Disassembly 1 D2 = Disassembly 2 LC = Lower Case UC1 = Upper Case 1 UC2 = Upper Case 2 KG = Keyboard Group
GRF = GRF0001006 HDD = HDD Group HG = Headphone Group DG = Dial Group MG = Main filter Group RLS = Right-left Side Group
