Pa2Xpro PART LIST
PART LIST RIGHT PANEL BOARD GRA0002131
CODE DESCRIPTION REFERENCE Q.TY
CIN0002012 CIRC.INT.TC74HC138 AFN SMD 2
CIN0010002 PSOC UC CYPRESS CY8C24423A-24SXI SOP28 1
CIN0010014 CIRCUITO LOGICO NOT, CD74ACT04M, SOP14 3
CON0001076 CONN.BLK PICOFLEX 16 VIE 1.27 1
CON0001072 CON.MASCHIO 6 VIE PH20W ITE 1
CON0010000 CONN. M. V. PTH, 2 FILE, 8 V, 1.27MM 1
CON0010016 CONN. M. V. PTH, 1 FILE, 3 V, 2.5MM, B3B-EH-A, JST 1
CON0010065 CONN. M. VER. PTH, 2 FILE, 6 VIE, 1.27MM MICS 06 1
DIX0006003 SMD DIODE RLS-4148 1
DIX0010004 DIODE ARRAY BAS16S/BAS16TW-MMBD4148TW 16
INT0001008 TACT SWITCH 46
LED0001004 LED DIODE BLUE 3MM PA1XPRO Update 17-04-2008* 26
LED0005004 LED DIODE BICOLOR 3MM RED/GREE ALTA EFF. 1
POT0001004 LINEAR POTENTIOMETER 10KB PAR.POL 1
TRS0002011 REG.+3.3V 1 A BA033FP 1
PART LIST OUTPUT BOARD GRA0002132
CODE DESCRIPTION REFERENCE Q.TY
CIN0003011 CIRC.INT. NMJ4556 AM SMD 1
CIN0010048 LOWNOISE LOW DIST MIC PREAMP INA217/SSM2019 1
CIN0010049 PSOC UC CYPRESS CY8C24123A-24SXI 1
CIN0010050 OPAMP 2CH NE5532D/NJM5532M SO8 9
CON0001078 CONN.BLK PICOFLEX 26 VIE 1.27 1
CON0005013 BLACK RCA PLUG GP305520 1
CON0010015 CONN. M. V. PTH, 1 FILE, 4V, 2,5MM, B4B-EH-A, JST 1
CON0010016 CONN. M. V. PTH, 1 FILE, 3V, 2.5MM, B3B-EH-A, JST 1
CON0010058 JACK STEREO 6.3MM NRJ6HH 6
CON0010059 COMBO CONNECTOR NEUTRIK NCJ10FI-H-0 1
DIX0006003 SMD DIODE RLS-4148 2
DIX0006004 SMD DIODE SHOTTLY RB051L-40TE25 4
DIX0010005 SCHOTTKY DIODE BAV99WT1G 6
DIX0010006 ZENER DIODE, VZ=33V 500MW MMSZ5257BT1G 1
DIX0010007 ZENER DIODE, VZ=16V 500MW MMSZ5246BT1G 1
LED0001004 LED DIODE BLUE 3MM PA1XPRO 1
POT0010001 POT. ROT. 270GR.1KC X1,RK09KC1110001KC1N20AC 1
TRA0001013 TRANSF. S/PIDIF DIGITAL AUDIO PE-65612 1
TRS0002001 TRANSISTOR NPN DTC114EKA SMD 4
TRS0002002 TRANSISTOR PNP DTA114EKA SMD 5
TRS0002004 TRANSISTOR NPN 2SD2114KT 10
TRS0002008 REGOLATOR 78L05(SOT89) 100MA SMD 1
TRS0002010 J-FET N CHANEL J108 SOT23 (PMBFJ108) 4
TRS0002016 TRANSISTOR PNP SMD VCE=45, IC=0.5, BC807 1
TRS0010005 N CH. MOSFET 1.9° 30V FDN357N 2
TRS0010006 P CH. MOSFET -2° -30V FDN360P 2
TRS0010007 TR. NPN SMD 80V, 500MA, PMBTA06/MMBTA06 1
TRS0010008 TR. PNP SMD 80V, 500MA, PMBTA56/MMBTA56 1
D1 = Disassembly 1 D2 = Disassembly 2 LC = Lower Case UC1 = Upper Case 1 UC2 = Upper Case 2 KG = Keyboard Group
GRF = GRF0001006 HDD = HDD Group HG = Headphone Group DG = Dial Group MG = Main filter Group RLS = Right-left Side Group
