Pa2Xpro PART LIST
PART LIST MP3 INTERFACE GRA0002109
CODE DESCRIPTION REFERENCE Q.TY
CIN0004005 RES.GEN.3,3V ETC811SUC 1
CIN0010037 SDRAM, 64MBIT, 16BIT, K4S641632K-UC75, SSOP54 1
CIN0010043 1 OF 2 DEMUX SN74LVC1G18DCKR 1
CIN0010044 TRIPLE N.INV. SCHMITT TRIG SN74LVC3G17DCTR 2
CIN0010046 DSP TI TMS320C6726BRFP266 HTQFP 1
CIN0010047 DC-DC CONV. ADJ 1,2A TPS62040DGQ 1
CON0010057 CON. M. V. SMD 2FILE 16V. 1.27MM MICS/SMD 16 RP 1
QUA0006005 X-CRYSTAL SMD HCM49 24.576MHZ 1
TRS0002011 REG.+3.3V 1 A BA033FP 1
PART LIST HD INTERFACE GRA0002120
CODE DESCRIPTION REFERENCE Q.TY
CIN0004005 RES.GEN.3,3V ETC811SUC 1
CIN0010020 CIRC. INTERF. USB TO ATA, TUSB6250, TI, TQFP80 1
CIN0010023 EEPROM, 256KBIT, 8BIT, 24LC256I/SNG, SO8 1
CON0001102 CONN. 44 PIN FOR HD I/F HRS A3E-44PA-2DSA 1
CON0010012 MALE CONN. PTH, 1 FILE, 7 V, 2,5MM, S7BEH, JST 1
QUA0010001 X-CRYSTAL SMD HCM49, 24MHZ, ARMONICA 1, 1
TRS0002001 TRANSISTOR NPN DTC114EKA SMD 1
TRS0002011 REG.+3.3V 1 A BA033FP 1
PART LIST LEFT PANEL BOARD GRA0002130
CODE DESCRIPTION REFERENCE Q.TY
ALT0001030 BUZZER PIEZO MURATA PKM17EPP-2002-B0 1
BAT0001001 BATTERY 3V 220MA CR2032 1
CIN0002012 I.C. TC74HC138 AFN SMD 2
CIN0010002 PSOC UC CYPRESS CY8C24423A-24SXI SOP28 1
CIN0010014 LOGIC CIRCUIT NOT, CD74ACT04M, SOP14 3
CIN0010051 RTC STM M41T00SM6E/DS1340-33+ 1
CON0001076 CONN. BLK PICOFLEX 16 VIE 1.27 1
CON0001087 MALE CONN.6 VIE PH20W6R ORIZ. 1
CON0010065 CONN. M. VER. PTH, 2 FILE, 6 V, 1.27MM MICS 06 1
CON0010064 CONN. SOCKET BATTERY CR2032 LT100-10 1
DIX0006003 SMD DIODE RLS-4148 1
DIX0010004 DIODE ARRAY BAS16S/BAS16TW-MMBD4148TW 15
INT0001008 TACT SWITCH 41
LED0001004 DIODO LED BLUE 3MM PA1XPRO Update 17-04-2008* 47
LED0005004 DIODO LED BICOLOR 3MM RED/GREE ALTA EFF. 1
POT0001004 LINEAR POTENTIOMETER 10KB PAR.POL 11
QUA0006012 X-CRYSTAL SMD 32.768KHZ SMD PKG CM200S 1
TRS0002002 TRANSISTOR PNP DTA114EKA SMD 1
D1 = Disassembly 1 D2 = Disassembly 2 LC = Lower Case UC1 = Upper Case 1 UC2 = Upper Case 2 KG = Keyboard Group
GRF = GRF0001006 HDD = HDD Group HG = Headphone Group DG = Dial Group MG = Main filter Group RLS = Right-left Side Group
