Pa2Xpro PART LIST
PART LIST MAIN BOARD GRA1002102
CODE DESCRIPTION REFERENCE Q.TY
CIN0002026 I.C.SN74AHCU04D HEX.UND. 1
CIN0002040 I.C.NJM4580M OP.AMP. 4
CIN0002074 I.C. SN74 LVC 125A QUAD BUFFER 3-STA 1
CIN0010000 CONV. D/A, 24BIT, DR=120DB, CS4398-CZ,TSSOP28 2
CIN0010001 CONV. A/D, 24BIT, DR=114DB, CS5361-KZ ,TSSOP24 1
CIN0010003 INTERF. USB HOST CONTR., ISP1761, LQFP128 1
CIN0010004 FPGA LFEC1E-3T100C, TQFP100 1
CIN0010007 DSP TAS3103 1
CIN0010025 1CH USB POWER SW. 0,5A-0,7A TPS2041BD, SOP8 2
CIN0010027 OPTOIS. PC410LENIP-OF, SOP6 1
CIN0010029 NANDFLASH,2GBIT,8BIT,K9F2G08U0M-PCB0,TSOP48 1
CIN0010030 PSOC UC CYPRESS CY8C27443-24SXI SOP28 1
CIN0010041 NOR FL,16MBIT,16BIT,MX29LV160CTTC-70G, TSOP48 1
CON0001075 CONN.BLK PICOFLEX 12 VIE 1.27 1
CON0001076 CONN.BLK PICOFLEX 16 VIE 1.27 1
CON0001078 CONN.BLK PICOFLEX 26 VIE 1.27 1
CON0001079 CONNETTORE USB 67068-0000 1
CON0005001 CIRCULAR 5-PIN DIN GQ004005 3
CON0005011 MIDI MG/PR6L STE.(EC.5) 1
CON0005012 STEREO JALCO JACK YKB21-5074G 2
CON0010000 CON. M. V. PTH, 2 FILE, 8 VIE, 1.27MM 1
CON0010001 CON. M. V. PTH, 2 F., 10 V., 1.27MM, 90325-0010 1
CON0010009 USB CONN. TYPE A, 1
CON0010012 MALE CONN. PTH, 1 FILE, 7 VIE, 2,5MM, S7BEH, JST 1
CON0010018 MALE CONN. PTH, 1 FILE, 5 VIE, 2,5MM, S5BEH, JST 1
CON0010039 STRIP M. V. PTH,2F,22V,2MM, H10 CH75442V111 3
CON0010022 CONN. M. V. PTH, 1 FILE, 6 V. 3,96MM, B6P-VH-K, JST 1
DIX0006000 DIODO DOPPIO SMD DA204KT146 9
DIX0006003 DIODO SMD RLS-4148 5
FER0010078 CUSNP AWG SPRING 2
QUA0006006 X-CRYSTAL SMD HCM49 33MHZ 1
QUA0010000 X-CRYSTAL SMD HCM49 12MHZ 1
TRS0002004 TRANSISTOR NPN 2SD2114KT 1
TRS0002006 REG.+5V 0.5° BA178M05FP 1
TRS0002007 REG.+3.3V 0.5A BA033FP 1
TRS0010000 LINEAR REG. -12V, 0,5A, NJM79M12, TO252 1
TRS0010001 LINEAR REG. 12V, 0.5A, 78M12, TO252 1
TRS0010002 LINEAR REG. 1,2V, 0,8A, LD1117S12, SOT223 1
TRS0010004 LINEAR REG. ADJ, 3A, LM1085ISX-ADJ, D2PACK 1
PART LIST KEYBOARD INTERFACE GRA1002105
CODE DESCRIPTION REFERENCE Q.TY
CIN0002012 CIRC.INT.TC74HC138 AFN SMD 3
CIN0002056 IC.SW/LED/KBD SCAN. (NKS3,5)HD6433394A35F(S) 1
CIN0010009 OPAMP. R.TO R. 2CH LMC662CM SOP8 1
CON0001048 MALE CONN. 4 V. P.2.54 1
CON0001076 CONN.BLK PICOFLEX 16 VIE 1.27 1
CON0001077 CONN.BLK PICOFLEX 20 VIE 1.27 1
CON0010001 CON. M. V. PTH, 2 F., 10 V., 1.27MM, 90325-0010 1
QUA0006004 X-CRYSTAL SMD HCM49 16MHZ 1
TRX0005002 TRIMMER ORIZ.P5MM 470K 1
D1 = Disassembly 1 D2 = Disassembly 2 LC = Lower Case UC1 = Upper Case 1 UC2 = Upper Case 2 KG = Keyboard Group
GRF = GRF0001006 HDD = HDD Group HG = Headphone Group DG = Dial Group MG = Main filter Group RLS = Right-left Side Group
