MIDI Implementation Chart
Appendix
MIDI Implementation Chart
Function Transmitted Recognized Remarks
Basic Channel
Default 1–16 1–16 Memorized
Changed 1–16 1–16
Mode
Default 3
Messages X X
Altered ****************
Note
Number:
0–127 0–127
True Voice **************** 0–127
Ve locity
Note On O 9n, V=1–127 O 9n, V=1–127
Note Off O 8n, V=0–127 O 8n, V=0–127
Aftertouch
Poly (Key) O O Player data only *1
Mono (Channel) O O *1
Pitch Bend
OO
Control
Change
0, 32 O O Bank Select (MSB, LSB) *1
1, 2 O O Modulations *1
6 O O Data Entry MSB *1
38 O O Data Entry LSB *1
7, 11, 16 O O Volume, Expression, Ribbon *1
10, 91, 93 O O Panpot, A/B Master FX Send *1
64, 66, 67 O O Damper, Sostenuto, Soft *1
65, 5 O O Portamento On/Off, Portamento Time *1
71, 72, 73 O O Harmonic Content, EG time (Release, Attack) *1
74, 75 O O Brightness, Decay Time *1
76, 77, 78 O O Vibrato Rate, Depth, Delay *1
98, 99 O O NRPN (LSB, MSB) *1, 2
100, 101 O O RPN (LSB, MSB) *1, 3
120, 121 X O All sounds off, Reset all controllers *1
Program
Change
O 0–127 O 0–127 *1
True # **************** 0–127
System Exclusive
OO *4
System
Common
Song Position X X
Song Select X X
Tune X X
System
Real Time
Clock O O *5
Commands O O *5
Aux
Messages
Local On/Off X X
All Notes Off X O (123-124)
Active Sense O O
Reset X X
Notes
*1: Sent and received when MIDI Filters In and Out are set to Off in Global mode.
*2: Drawbar settings, Drawbars settings, Sound parameters, Selection of SongBook entries, Drum Kit Family settings.
*3: LSB, MSB = 00,00: Pitch Bend range, =01,00: Fine Tune, =02,00: Coarse Tune.
*4: Includes Inquiry and Master Volume messages, FX settings, Quarter Tone settings. GM Mode On.
*5: Transmitted only when the Clock Send parameter (Global mode) is set to on.
Mode 1:OMNI ON, POLY
Mode 3:OMNI OFF, POLY
Mode 2:OMNI ON, MONO
Mode 4:OMNI OFF, MONO
O: Yes
X: No
KORG Pa900
OS Version 1.0 - March 01, 2013
