12
*1 Be sure to use only the specified AC adapter (DC4.5V
).
*2 If a CD player or other audio source is connected to
the AUX jack, you can play along with your guitar or
bass. However the volume must be adjusted from the
connected device.
Connecting cables are sold separately.
*3 The PX5D’s output jack is stereo. If you use a mono
cable to connect it to a guitar or bass amp etc., only
the L (left) output will be heard.
*4 The PX5D’s output level and sound quality will vary
depending on which headphones are used. We rec-
ommend using good quality low impedance head-
phones, 32 Ohms or less with a sensitivity rating near
100dB/mW or above. Many headphones sold for use
with portable CD or cassette players will work fine.
*5
Use the included cable for FOOT SW jack to connect
two foot switches to the PX5D. You can connect two
foot switches such as the Korg PS-1 (sold separately).
In Utility mode you can specify the function of the
pedal switches; for example you can use them to
switch programs, or to start/stop recording and play-
back in Phrase Trainer mode (☞p.16 “Using foot
switches to select programs,” ☞p.34 “FOOTSW”).
*6 Use the included USB cable if you want to connect
the PX5D to your computer. For details on connec-
tions to your computer, refer to “Connecting to your
computer.”
*7 If needed, you can attach the included rubber feet to
the bottom of the PX5D.
