Korg TR - Page 236

229
Appendices
TR controller Available
for AMS
Available
for DMOD
Joy Stick Realtime
Controls
A
Realtime
Controls
B
Arp-Gate
(Realtime
Controls C)
Arp-Velocity
(Realtime
Controls C)
SW1,2 ARP
On/Off
Damper Assign-
able
Switch
Assign-
able Pedal
MIDI channel messages
Note-off
Note-on (note number) **
Note-on (velocity) **
Poly after touch *
CC# 0 Bank select (MSB) *
1 Modulation 1 # (+Y) * **
2 Modulation 2 # (–Y) * **
3– *
4Foot controller * ***
5Portamento time *
6 Data entry (MSB) *
7Volume * *
8Post insertion effect panpot * *
9– *
10 Panpot * *
11 Expression * *
12 Effect control 1 * **
13 Effect control 2 * **
14...15 *
16 Ribbon controller * **
17 Knob modulation 1 * **
18 Controller (CC#18) * **
19 Knob modulation 2 * **
20 Knob modulation 3 * **
21 Knob modulation 4 * **
22...31 – *
32 Bank select (LSB) *
33...37 – *
38 Data entry (LSB) *
39...63 – *
64 Damper * #**
65 Portamento On/Off * * * * *
66 Sostenuto On/Off * ***
67 Soft * **
68...69 – *
70 Sustain level *
71 Filter resonance level/High pass
filter cutoff frequency
* (Knob2) *
72 Release time * (Knob4) *
73 Attack time *
74 Low pass filter cutoff frequency * (Knob1) *
75 Decay time *
76 LFO1 speed *
77 LFO1 depth (pitch) *
78 LFO1 delay *
79 Filter EG intensity * (Knob3) *
80 SW1 modulation On/Off * * (SW1) * *
81 SW2 modulation On/Off * * (SW2) * *
82 Foot switch On/Off * ***
83 Controller (CC#83) * **
84...90 - *
91 Effect depth 1 (send 2 level) * *
92 Effect depth 2 (insertion effect
On/Off )
*
93 Effect depth 3 (send 1 level) * *
94 Effect depth 4 (master effect 1
On/Off)
*
95 Effect depth 5 (master effect 2
On/Off)
*
96 Data increment
97 Data decrement
98 NRPN(LSB)
2: Arpeggiator on/off switch #*
10: Arpeggiator gate control #
11: Arpeggiator velocity control #
99 NRPN(MSB) 0 # # # *
100 RPN(LSB)
0: Bend range
1: Fine tune
2: Coarse tune
101 RPN(MSB) 0
102...127 -
Program change
Channel after touch **
Bender change # (X) **
Universal exclusive
Master volume * *
Master balance
Master fine tune
Master coarse tune
