Faults
The guarantee does not cover the above repairs.
If there is a fault in the appliance (the heater does not work and all the above reasons
do not occur), contact the nearest authorised service.
In case the unit does not heat the water, check for possible reasons:
Fault Reason
control lights off power supply failure
unit doesn’t heat up the wa-
ter/ water temp. is too low
power supply failure
water ow rate is too low (e.g. lter is blocked with
impurities)
Technical data
The minimal resistivity of water at 15
0
C for PPH2 and KDH2 is 1100 Ω cm.
Hydraulic instantaneous water heater
PPH2,
KDH2
KDH
PPH2,
KDH2
KDH
PPH2,
KDH2
KDH
PPH2,
KDH2
KDH
PPH2,
KDH2
KDH
KDH
Rated power kW 9 12 15 18 21 24
Rated voltage 400V 3~
Rated current A 3 x 13,0 3 x 17,3 3 x 21,7 3 x 26,0 3 x 30,3 3 x 34,6
Supply water pressure MPa 0,15 - 0,6 0,2 - 0,6 0,25 - 0,6
Operating point
position I l/min
1,9
1,8
2,3
2,3
3,2
2,9
3,6
3,5
4,3
4,1
4,7
position II l/min
3,1
2,8
3,8
3,7
4,7
4,6
5,1
5,5
6,1
6,4
7,3
Efciency (at Δt = 30°C and 0,4 MPa) l/min 3,3 4,3 5,4 6,5 7,6 8,7
Overall dimension (height without tap set x
width x depth)
mm
PPH2 440 x 245 x 126
KDH, KDH2 440 x 245 x 120
Weight
PPH2
kg
~4,0
KDH2 ~4,3
KDH ~5,2
Fuse rated current A 16 20 25 32 40
Min. connecting wires section mm
2
4 x 1,5 4 x 2,5 4 x 4 4 x 6
Max. connecting wires section mm
2
4 x 16
The maximum allowed network impedance Ω 0,43 0,37
Water supply pipe section G 1/2” (distance between inlet and outlet 100 mm)
