13
Rain sensor button Switch rain sensor On/Off. The indicator light is on to allow
the device to work in rain; If the light is off, the device will return to the charging pile
after detecting rain.
Press unlock button , START button and OK button in order, then the
mower will start mowing.
Press unlock button , then press HOME button and OK button
It is allowed to stop your robotic mower by pressing the STOP button in any situations.
The stop button has the highest priority, the robotic mower will stop immediately in
any case.
The cutting height can be adjusted by rotating the height adjustment knob.
Cutting height range from 20mm- 55mm.
OK button Used with the Start/Home button.
GPS signal indicator LED will remain on only when the GPS signal is normal.
Rain sensor button
Start mowing
Return to charging station
Stop the robotic mower
Cutting height adjustment
Basic Operation
OK button
