5
Preparing your lawn for the Robot Mower
Boundary wire Charging station
Max 5mm
Min 100cm Min 100cm
Min 100cm
Min 100cm
Min 30cm
Min 30cm
Min 30cm
Min 30cm
Min 50cm
M
i
n
3
0
c
m
Obtuse angles Curves Don't cross wires
If a tree root is protruding
into the perimeter of your
cutting area it would
present a problem for the
mower.
One solution is to take the
perimeter around the tree
root, leaving this area
unmowed.
Alternatively, cut the tree
root back with a saw and
fill any resulting uneven
surface, then set the
perimeter over it.
No right angles No acute angles
Rectifying or avoiding problem areas Obstacles such as tree roots on lawn
The boundary wire will transmit an
electromagnetic signal to the robot mower so
that it can recognize its position in the garden.
