5-6 BA 35101/02/03 EN – Edition 1.0 * 35101_02_03b510.fm
Maintenance
Filling up engine oil
Too much or incorrect engine oil can result in engine damage!
☞ Do not add engine oil above the MAX mark of the oil dipstick A
☞ Use only the specified engine oil –seeFluids and lubricants on page 5-43
Use a suitable container to collect the engine oil as it drains and dispose of it in
an environmentally friendly manner!
☞ Fill up the engine oil as follows:
• Clean the area around oil filler cap B with a lint-free cloth
• Open filler cap B
• Pull out oil dipstick A and wipe it with a lint-free cloth
• Fill in engine oil
• Wait a moment until all the oil has run into the oil sump
• Check the oil level with oil dipstick A –seeChecking the engine oil level on page 5-5
• Fill up oil if necessary and check the oil level again
• Close filler cap B and completely remove all oil spills from the engine
Fig. 160: Oil dipstick and oil filler cap
A
B
