Technical Specifications
9
6 Technical Specifications
1
Table 4 includes the technical specifications of the 711N, and the 712N
2
:
Table 4: Technical Specifications of the 711N and the 712N
711N 712N
INPUT:
1 composite video 1Vpp/75, on a BNC
connector; 1 stereo unbalanced audio
4dBm/50k, on two RCA connectors
1 RJ-45 CAT-5 shielded connector
(LINE IN)
OUTPUT: 1 RJ-45 CAT-5 shielded connector
(LINE OUT)
1 composite video 1Vpp/75, on a BNC
connector; 1 stereo unbalanced audio
4dBm/50k, on two RCA connectors
VIDEO MAX. SIGNAL LEVEL:
>100kHz
DIFF. GAIN: 0.04%
DIFF. PHASE: 0.25 Deg.
K-FACTOR: 0.1%
VIDEO S/N RATIO: 75dB
AUDIO S/N RATIO: 77dB
AUDIO CROSSTALK (all
hostile)
-53dB @ 5MHz, video into audio
CONTROLS
LEVEL: -1.3dB to +6.3dB
EQ @ 30MHz: 0dB to +3.7dB
VIDEO COUPLING: DC
AUDIO COUPLING: Input: AC; line output: DC DC for both line input and output
AUDIO THD + NOISE: 0.026%, 1kHz
AUDIO 2nd HARMONIC: 0.001% @ 1kHz
POWER SOURCE: 12 VDC 50mA, when 712N is fed by
an independent 12V supply; 135mA
when feeding 712N
12 VDC 45mA, when 711N is fed by
an independent 12V supply
DIMENSIONS: 12cm x 7.15cm x 2.76cm (4.7" x 2.8" x 1.08"), W, D, H
WEIGHT: 0.3 kg. (0.67 lbs.) approx. (each)
ACCESSORIES: Power supply, mounting bracket (each)
OPTIONS: RK-T1, RK-T3, 19 inch rack adapters
1 Specifications are subject to change without notice
2 Specifications for 100m of CAT5 UTP cable, unless otherwise specified
