Kramer 712N User Manual

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your Video-Audio Line Transmitter/Receiver
4
Lower Side Panel
Top Side Panel
Figure 2: 711N Video-Audio Line Transmitter – Top and Lower Side Panels
Table 1: 711N Video-Audio Line Transmitter Features
# Feature Function
1 VIDEO IN BNC Connector Connect to composite video source
2 LINE OUT CAT5 Connector
Connect to the LINE IN RJ-45 connector on the 712N
3 LEFT RCA
Connector
Connect to the left unbalanced stereo audio source
4
AUDIO
IN
RIGHT RCA
Connector
Connect to the right unbalanced stereo audio source
5 12V DC +12V DC connector for powering the unit
6 ON LED
Lights when receiving power from the 712N, or
directly from the power adapter
4.2 Your 712N Video-Audio Line Receiver
Figure 3, Figure 4 and Table 2 define the 712N Video-Audio Line Receiver:

Kramer 712N Specifications

General

Brand	Kramer
Model	712N
Category	Receiver
Language	English
