5 Operation
Tilt ram lock (option)
This option is used for securing the tipping cylinder if it should not be
operated (for example when setting down material on high piles).
A work platform may not be mounted.
The tilt-ram lock is enabled with key-operated switch C in the switch
console under the armrest.
Switching on the tilt ram lock
1. Set the loader unit to transport position.
2. Set the tilt ram and the material to the required position.
3. Turn key-operated switch C to position A.
➥ The tilt ram is locked and can no longer be operated in the position
to which it has been adjusted.
4. Set down the load.
Switching off the tilt-ram lock
1. Turn key-operated switch C to position B.
➥ Tilt ram is unlocked.
