BA 35203_04 * 3.0 * 35203_04_05_Bedienung.fm 5-125
Operation 5
Low-speed control with regulated travel speed (option)
Important information on the low-speed control with regulated
travel speed (CSD = Control Speed Drive)
Using this function, an even driving speed can be achieved. The selected
driving speed is largely self-contained of the driving resistance.
When operating hydraulically activated attachments (e.g. sweepers or
ground mills), the function of the low-speed control ensures an even
driving speed or starting from a standstill with a high engine speed.
With the sliding control, 32 the driving speed can be variably set
regardless of the engine speed.
Danger of accident due to fast acceleration of the machine!
Can cause serious injury or death.
► If a high speed is still pre-set via the manual throttle function, consider
the saved speed and the resulting vehicle behavior before actuating
the travel direction touch button.
Operate low-speed control only in conjunction with the manual throttle
option – see “Manual throttle (option)” on page 5-10.
Operation of low-speed control is only possible from an engine speed of
about 1100 rpm and in the ”Turtle” speed range
– see “Changing speed range” on page 5-19!
The low speed control is not effective in the "hare" speed.
In order to achieve the maximum speed in the "Turtle" speed in normal
application, the slide control 32 must be pushed forward to the detent
(A).
If the slide control 32 is in position B, the vehicle will not drive.
