7 Maintenance
Cleaning the exterior of the machine
Damage to machine due to cleaning work.
► Pay attention to the lower side in particular when cleaning the
machine. Do not allow dirt to collect on the engine or gearbox.
► Do not damage the radiator fins when cleaning with a high-pressure
cleaner.
► Always cover the intake connection of the air filter before washing the
engine.
► Do not point the water jet of the high-pressure cleaner at the seals of
hydraulic cylinders.
► Do not clean electrical components (instrument panel, alternator,
compact connectors, control levers, etc.) with a high-pressure cleaner.
Damage due to rusting on paint finish, joints, screwed connections, etc.
► Thoroughly clean the machine with water after performing machine
travel on saline ground or roads and going to a different site!
The following aids are recommended for cleaning:
• High-pressure cleaner
• Steam jet
