9-4 BA 35203_04 * 3.0 * 35203_04_09_Technische_Daten.fm
9 Technical data
Variable displacement motor
Machine 20 km/h
20 km/h (optional)
1
30 km/h or 40 km/h
(optional)
1. Vehicle with high speed option (ICVD)
Design
Axial piston motor
(swash plate design)
Capacity 110 cm³/rev ( 6.71 in³/rev) 233 cm³/rev(14.22 in³/rev)
Travel speed
2
(forward and
reverse)
2. The maximum speed is reached when the drive has a minimum temperature of 20–30 °C (68 °F–86
°F), on level, asphalted ground, without a trailer and with an empty bucket.
1st speed range:
0–7 kph
(0 – 4.35 mph)
2nd speed range:
0 – 20 kph
(0 – 12.43 mph)
1st speed range:
0–7 kph
(0–4.35mph)
2nd speed range:
0 – 30/40 kph
(0 – 18.64/24.85 mph)
Pushing power
(tires
16/70-20)
352-03S:
51 kN (11.465 lbf)
352-04S/L:
57 kN (12.814 lbf)
352-03S:
52 kN (11.690 lbf)
352-04S/L:
55 kN (12.364 lbf)
Pushing power
(tyres
405/70-24)
352-03S:
47 kN (10.566 lbf)
352-04S/L:
53 kN (11.915 lbf)
352-03S:
48 kN (10.791 lbf)
352-04S/L:
51 kN (11.465 lbf)
