Always switch off the power to each device before connecting it to your
Transmitter and Receiver. After connecting your Transmitter and
Receiver, connect their power and then switch on the power to each
device.
You can use the TP-580T HDMI Line Transmitter and the TP-580R HDMI Line
Receiver to configure an HDMI transmitter/receiver system, as shown in the
example in Figure 4.
To connect the TP-580T, connect the:
1. HDMI source (for example, a DVD player) to the HDMI IN connector.
2. RS-232 9-pin D-sub connector to a computer (for example, a laptop to
control the projector).
3. IR 3.5mm mini jack to an IR emitter.
4. HDBT OUT RJ-45 connector over twisted pair to the TP-580R HDBT IN
connector.
Alternatively, you can use any other certified HDBaseT receiver device (for example,
the Kramer WP-580R)
5. 12V DC power adapter to the power socket and connect the adapter to the
mains electricity (not shown in Figure 4).
To connect the TP-580R, connect the:
6. HDMI OUT connector to the HDMI acceptor (for example, a projector).
7. RS-232 9-pin D-sub connector to an RS-232 port (for example, a projector that is
controlled by the laptop connected to TP-580T).
8. IR 3.5mm mini jack to an IR sensor.
9. HDBT IN RJ-45 connector over twisted pair to the TP-580T HDBT OUT
connector.
Alternatively, you can use any other certified HDBaseT transmitter device (for example,
the Kramer WP-580T)
10. 12V DC power adapter to the power socket and connect the adapter to the
mains electricity (not shown in Figure 4).
