RMP-SD8R rear
Paired with VIP4 processing cards, this rear allows up to eight 3G SDI inputs via micro-BNC coax connectors. This signal
architecture allows up to eight single 3G inputs, or four dual-link 6G inputs or two two quad-link 12G inputs – or a
combination of all three input types.
The SD8R is designed to be used with the router based SMP-xx-R family.
RMP-SD8R
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP4 NET MVC MVC2 VIP3 AIP/AOP
X √ X √ √ X √ X √
INPUTS SUPPORTED ROUTER INPUTS SUPPORTED
VIDEO
CARD
SD-60 HD-60/
FHD-30
FHD-60 UHD-30 UHD-60 SD-60 HD-60/ FHD-30 FHD-60 UHD-30 UHD-60
VIP 4
√ √ √ √ √ √ √ √ √ √
Version 0.5
R IN 1
R IN 2
R IN 3
R IN 4
R IN 5
R IN 6
R IN 7
R IN 8
SDI 8
SDI 7
SDI 6
SDI 5
SDI 4
SDI 3
SDI 2
SDI 1
