Kramer SMP Series - Signal Output Cards

Signal Output Cards
MPX-MVC-SD
FOR USE WITH THE VIP4 ONLY
2 x independent HDMI/DVI each with slaved SDI outputs
Video Standards
supported
HDMI output With embedded
audio
Slaved SDI output With embedded
audio
UHD 4K25 RGB 4:4:4
(3840x2160@25Hz)
✓ ✓
✓
1
✓
UHD 4K30 RGB 4:4:4
(3840x2160@30Hz)
✓ ✓
✓
1
✓
UHD 4K50 YCbCr 4:2:0
(3840x2160@50Hz)
✓ ✓
✓
2
✓
UHD 4K60 YCbCr 4:2:0
(3840x2160@60Hz)
✓ ✓
✓
2
✓
Notes:
1. SMPTE ST 2081-10 6Gbps supported
2. Depending on rear selected quad-link or SMPTE ST 2082-10 12Gbs supported
Audio Meter Scales and Ballistics
Overall dynamic range: Attack time: Decay time:
NORDIC:
54dB (+12 to -42dB) 10mSec 1.7Sec per 20dB decay
DIN PPM:
55dB (+5 to -50dB) 10mSec 2.8Sec per 24dB decay (from "Mark 7" to
"Mark 1")
BBC PPM:
24dB +3dB down "Mark 1"
(+12 to-12dB)
10mSec 2.8Sec per 24dB decay (from "Mark 7" to
"Mark 1")
VU:
23dB (+3 to -20dB) 300mSec 300mSec per 20dB decay
VU EXT:
60dB (+10 to -50dB) 300mSec 300mSec per 20dB decay
AES/EBU:
60dB (0 to -60dB) < 5ms 1.5Sec per 20dB decay
Version 0.5
