Rear Input/Output cards
MPX-RNG (network) rear
This is the only rear that has a different mechanical format between the 1U and 3U Frames. The signal connectivity is
identical, the only difference is the 3U version has a wider rear plate. All other rears are identical in form and functionality and
can be used in either sized frame.
MPX-RNG rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
SMP-xx SMP-xx-R MP-xx NET
√ √ √ √
Version 0.5
REF
TIME
CODE
RS422
LAN
GPIO
To Next Page
