Main Frame MP-xx
Mechanical MP-xx frame – 3U high 19” Rack Mounting Frame with removable front panel,
temperature controlled fan assisted ventilation, 20 card slots, separate rear connector
modules and power supply / fan status indicators.
Outline Dimensions~: 440mm(W) x 455mm(D) x 132mm(H)
Weight: 10.5kg (full frame)
Power Connectors: AC - Single IEC Mains Socket
DC – Single 2-pole DC power socket
Consumption: Maximum power consumption 576W
Input current rating 7A AC, 24A DC
Fuses 1x 3.15A Fuse; 5x20mm ceramic body, Anti-
surge/Time delay inside IEC socket
Environmental Operating Temperature 0°C to 40°C
Relative Humidity 70% max, non-condensing
Ventilation Fan assisted. Front Inlet, rear exhaust
Compliance EMC – Emissions EU: EN55103-1
USA: 47 CFR: 2009, Part 15, Sub-part B (Class A)
EMC – Immunity EU: EN55103-1
Safety EN: EN60950-1
USA: Tested to UL1419 (3
rd
Edition)
Hazardous Material UK: RoHS-6 – Complies with EU Directive
Front panel Power supply and fan failure LED indicators on front panel
1 x OLED display and control knob
1 x USB type A port
1 x 6.35mm stereo audio socket
Version 0.5
