Kramer SMP Series - Signal Output Cards

Signal Output Cards
MPX-MVC
FOR USE WITH THE VIP3 ONLY
2 x independent HDMI/DVI each with slaved SDI outputs
Video Standards supported HDMI output With embedded
audio
Slaved SDI
output
With embedded
audio
720p50 (1280x720@50Hz)
✓ ✓ ✓ ✓
720p59.94 (1280x720@59.94Hz)
✓ ✓ ✓ ✓
720p60 (1280x720@60Hz)
✓ ✓ ✓ ✓
1080p50 (1920x1080@50Hz)
✓ ✓ ✓ ✓
1080p59.94 (1920x1080@59.94Hz)
✓ ✓ ✓ ✓
1080p60 (1920x1080@60Hz)
✓ ✓ ✓ ✓
XGA
(1024x768@60Hz)
✓
SXGA+ (1400x1050@60Hz)
✓
1600x1200@60Hz
✓
Audio Meter Scales and Ballistics
Overall dynamic range: Attack time: Decay time:
NORDIC:
54dB (+12 to -42dB) 10mSec 1.7Sec per 20dB decay
DIN PPM:
55dB (+5 to -50dB) 10mSec 2.8Sec per 24dB decay (from "Mark 7" to "Mark 1")
BBC PPM:
24dB +3dB down "Mark 1"
(+12 to-12dB)
10mSec 2.8Sec per 24dB decay (from "Mark 7" to "Mark 1")
VU:
23dB (+3 to -20dB) 300mSec 300mSec per 20dB decay
VU EXT:
60dB (+10 to -50dB) 300mSec 300mSec per 20dB decay
AES/EBU:
60dB (0 to -60dB) < 5ms 1.5Sec per 20dB decay
Version 0.5
