VIDEO INPUT CARDS
VIP4
8 video inputs per card:
SDI input standards
supported:
SD-SDI (SMPTE259M 270Mb): 525/60, 625/60
HD-SDI (SMPTE292M 1.5Gbs)
3G-SDI (SMPTE424M Level A Mapping 3Gbs)
6G-SDI (SMPTE ST-2081 6Gbs). Inputs 1, 3, 5 and 7.
12G-SDI (SMPTE ST-2082 12Gbs) using quad-link or 12G direct using specific rears .
Up to two 12G inputs/VIP4.
SD-Analogue: Composite (CBVS 1V P-P) available on certain rears
Embedded audio
Embedded audio derived from SDI (up to 16 channels per source)
HDMI
Dolby E meter segment metadata level metering (optional)
Video Processing Processing delay varies from 2-3 fields for interlaced video inputs, 2-3 frames for
progressive video inputs, depending on timing relationship between the input and
output.
Alarms Video inputs Loss of sync, loss of luminance, freeze frame
Audio inputs Loss of embedded or external audio, over-level, out of phase
channel pairs
Metadata
inputs
Loss of VITC (SDI only), loss of V-Chip (composite only), teletext
(analogue only), subtitles, video non-sync detection
Alarm
indication
Visual (in display), GPI, LAN, SNMP traps
Metadata Decoding
/monitoring
Teletext (WST) subtitles (ITU-R BT.653-3) SD-SDI only
OP-47 subtitles, SD- HD- 3G-SDI
AFD driving aspect ratio (SMPTE 2016-2007), SD- HD- 3G-SDI
WSS driving aspect ratio (ETSI EN 300 294), composite only
D-VITC timecode display (SMPTE-12M-2008 VITC), SD-SDI only
ATC timecode display (SMPTE-12M-2008 ATC), SD- HD- 3G-SDI
Version 0.5
