VIP 3
4 video inputs per card
SDI input
standards
supported:
SD-SDI (SMPTE259M 270Mb): 525/60, 625/60
HD-SDI (SMPTE292M 1.5Gbs).
3G-SDI (SMPTE424M Level A Mapping 3Gbs)
SD-Analogue: Composite (CBVS 1V P-P) available on certain rears (please see the Summary
of rear connector modules table): PAL, PAL-M, NTSC, NTSC-4.43, SECAM
HDMI input
standards
supported:
SVGA (800x600 @ 60Hz)
XGA (1024x768 @ 60Hz)
SXGA (1280x1024 @ 60Hz)
UXGA (1600x1200 @ 60Hz)
1400x1050 @ 60Hz
852x480 @ 60Hz
1280x720 @ 60Hz
1366x768 @ 60Hz
960x540 @ 60Hz
720x480 @ 60Hz
1920x1080 @ 60Hz
1920x1080 @ 25,30Hz (interlaced)
In addition to the above, the HDMI receivers will handle any resolution with a clock frequency in the
range of 25MHz to 165MHz.
Embedded
audio
Embedded audio derived from SDI (up to 16 channels per source)
HDMI
Dolby E meter segment metadata level metering (optional)
Video
Processing
Processing delay varies from 2-3 fields for interlaced video inputs, 2-3 frames for progressive
video inputs, depending on timing relationship between the input & output.
Alarms Video inputs Loss of sync, loss of luminance, freeze frame
Audio inputs Loss of embedded or external audio, over-level, out of phase channel pairs
Metadata
inputs
Loss of VITC (SDI only), loss of V-Chip (composite only), teletext (analogue
only), subtitles, video non-sync detection
Alarm
indication
Visual (in display), GPI, LAN, SNMP traps
Metadata Decoding
/monitoring
Teletext (WST) subtitles (ITU-R BT.653-3) SD-SDI only
OP-47 subtitles, SD- HD- 3G-SDI
AFD driving aspect ratio (SMPTE 2016-2007), SD- HD- 3G-SDI
WSS driving aspect ratio (ETSI EN 300 294), composite only
D-VITC timecode display (SMPTE-12M-2008 VITC), SD-SDI only
ATC timecode display (SMPTE-12M-2008 ATC), SD- HD- 3G-SDI
