MV HDMI and SDI video output standards
The following table summarises the video standards available from the two independent HDMI (or DVI) output connectors on
the RMP-MVC, RMP-DV2SD2 or RMP-MVC2 rears along with the corresponding outputs on each of their slaved SDI
connections.
Video outputs: 2 x
independent HDMI each with
slaved SDI outputs
HDMI
output
With embedded
audio
Slaved SDI output With embedded audio
Using the MPX-MVC output card with the VIP3 (please see the Video outputs up to 4K section for more details on
card/rear combinations available)
720p50 (1280x720@50Hz)
✓ ✓ ✓ ✓
720p59.94
(1280x720@59.94Hz)
✓ ✓ ✓ ✓
720p60 (1280x720@60Hz)
✓ ✓ ✓ ✓
1080p50
(1920x1080@50Hz)
✓ ✓ ✓ ✓
1080p59.94
(1920x1080@59.94Hz)
✓ ✓ ✓ ✓
1080p60
(1920x1080@60Hz)
✓ ✓ ✓ ✓
XGA
(1024x768@60Hz)
✓
SXGA+ (1400x1050@60Hz)
✓
1600x1200@60Hz
✓
Using the MPX-MVC-LC/SD output card with the VIP3 or VIP4 (please see the Video outputs up to 4K section for
more details on card/rear combinations available)
UHD 4K25 RGB 4:4:4
(3840x2160@25Hz)
✓ ✓
✓
1
✓
UHD 4K30 RGB 4:4:4
(3840x2160@30Hz)
✓ ✓
✓
1
✓
UHD 4K50 YCbCr 4:2:0
(3840x2160@50Hz)
✓ ✓
✓
2
✓
UHD 4K60 YCbCr 4:2:0
(3840x2160@60Hz)
✓ ✓
✓
2
✓
Notes:1. SMPTE ST 2081-10 6Gbps supported
2. Depending on rear selected quad-link or SMPTE ST 2082-10 12Gbs supported
Processing delay varies from 2-3 fields for interlaced video inputs, 2-3 frames for progressive video inputs,
depending on timing relationship between the input and output.
