RMP-MVC rear
This is a 2K output rear Two independent video outputs are provided via each HDMI connector, each of which is paired
with a BNC providing a slaved SDI output. HDMI and SDI outputs contain embedded audio. A standard RJ45 connector is
provided as a LAN connection from which the multi-viewer browser control application is accessed.
RMP-MVC rear (connectors and pcb, shown here with H-Lok HDMI
retention brackets)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME
WITH THIS REAR
SMP-XX SMP-XX-R MP-XX MVC NET VIP3 VIP4 AIP/AOP
√ √ √ √ √ √ X √
Version 0.5
LAN
OUT 2
OUT 1
