RMP-MVCS8-MBNC rear
This is a 4K capable output rear fitted with two Type A HDMI connectors Two independent 4K video outputs are
provided via each HDMI connector, each of which is paired with four of the micro-BNC coax connectors providing quad-
link 12G SDI outputs. HDMI and SDI outputs contain embedded audio. A standard RJ45 connector is provided as a LAN
connection from which the multiviewer browser control application is accessed.
RMP-MVCS8-MBNC rear (connectors and pcb, shown here with H-Lok HDMI retention
brackets)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX MVC2 NET VIP3 VIP4SD AIP/AOP
√ √ √ √ √ X √ √
Version 0.5
LAN
HDMI 1
HDMI 2
SDI1-1
SDI1-2
SDI1-3
SDI1-4
SDI2-1
SDI2-2
SDI2-3
SDI2-4
