RMP-SD4 rear
With four BNC connectors capable of accepting up to 3G SDI inputs and a 15 way D-type GPIO connector.
RMP-SD4 rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
√ X √ √ √ X √ X √
INPUTS SUPPORTED
VIDEO CARD SD-60
HD-60/
FHD-30
FHD-60
VIP 3 √ √ √
NOTES:
Primarily designed to work with the four channel VIP3 processing cards either for use in SDI only architectures or in mixed
signal environments alongside the RMP-HM4 and RMP-CV4.
Version 0.5
SDI 4
SDI 3
SDI 2
SDI 1
GPIO
