RMP-SD4R rear
Designed for the SMP-xx-R, the SD4R, is available fitted with eight miniature bncs offering four 3G SDI inputs and four 3G
SDI outputs. A 15 way GPI/O connector is also included.
RMP-SD4R rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
X √ X √ √ X √ X √
INPUTS SUPPORTED OUTPUTS SUPPORTED
VIDEO CARD SD-60 HD-60/ FHD-30 FHD-60 SD-60 HD-60/ FHD-30 FHD-60
VIP 3 √ √ √ √ √ √
Version 0.5
OUT 4
OUT 3
OUT 2
OUT 1
IN 4
IN 3
IN 2
IN 1
GPIO
