RMP-HM4 rear
Where source equipment is fitted with HDMI outputs, the HM4 offers four Type A HDMI inputs along with a 15 way GPI/O
connector.
RMP-HM4 rear (connectors and pcb, shown here with H-Lok HDMI retention
brackets)
FRAME
COMPATIBILITY
ASSOCI
ATED
CARD
OTHER CARDS THAT CAN BE USED IN
THE FRAME WITH THIS REAR
SMP-
XX
SMP-
XX-R
MP-
XX
VIP3 NET MVC2 MVC VIP4
AIP/A
OP
√ X √ √ √ X √ X √
VIDEO CARD HDMI STANDARDS
VIP3 SVGA (800x600 @ 60Hz) √ VIP3 1280x720 @ 60Hz √
VIP3 XGA (1024x768 @ 60Hz) √ VIP3 1366x768 @ 60Hz √
VIP3 SXGA (1280x1024 @ 60Hz) √ VIP3 960x540 @ 60Hz √
VIP3 UXGA (1600x1200 @ 60Hz) √ VIP3 720x480 @ 60Hz √
VIP3 1400x1050 @ 60Hz √ VIP3 1920x1080 @ 60Hz √
VIP3 852x480 @ 60Hz √ VIP3
1920x1080 @ 25,30Hz
(interlaced)
√
Version 0.5
HDMI 4
HDMI 3
HDMI 2
HDMI 1
GPIO
