RMP-CV4 rear
For use with with composite inputs only, the CV4 is designed for cvbs applications providing four independent inputs via BNC
connectors. State of the art CVBS decoders use frame comb decoding techniques to provide optimum separation of
luminance and chrominance components and is ideally suited to CCTV applications or where the input source requires time
base correction.
RMP-CV4 rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
√ X √ √ √ X √ X √
INPUTS SUPPORTED
VIDEO CARD CVBS
VIP 3 √
Version 0.5
CVBS 4
CVBS 3
CVBS 2
CVBS 1
