RMP-SD4L rear
Utilising eight 3G SDI micro-BNC coax connectors, this rear has a loop-through output on each of its four video inputs in
order to ease connectivity issues where space is at a premium. A 15 way GPI/O connector is also included.
RMP-SD4L rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
√ NO √ √ √ X √ X √
INPUTS SUPPORTED OUTPUTS SUPPORTED
VIDEO CARD SD-60 HD-60/ FHD-30 FHD-60 SD-60 HD-60/ FHD-30 FHD-60
VIP 3 √ √ √ √ √ √
Version 0.5
GPIO
SDI4
LOOP4
LOOP3
LOOP2
LOOP1
SDI3
SDI2
SDI1
