The VIP4 video processing card utilises the latest generation of scaling technology in order to be able to process inputs up to
4K60. With the appropriate rears fitted, the combinations of video input types supported are:
Input Supported RMP-SD8 RMP-SD8R
Up to 8x SD/HD/3G-SDI √ √
2x 4K60 quad-link (12G) SDI digital video √ √
Up to 4x 4K30 dual-link (6G) SDI √ √
4x 6G-SDI direct √ √
2x 12G-SDI direct √ √
MV-VIP4 pcb
VIP4- designed to work with the new 4K capable output rear MPX-RMV2 and video output card MPX-MVC2-SD in order to
provide the highest resolution 4K I/O solution.
Version 0.5
