VM‑4HDT, VM‑3HDT, VM‑2HDT – Introduction
2
Safety Instructions
Caution:
There are no operator serviceable parts inside the unit.
Warning:
Use only the Kramer Electronics input power wall adapter that is provided
with the unit.
Warning:
Disconnect the power and unplug the unit from the wall before installing.
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
Overview
Congratulations on purchasing your Kramer HDMI to HDBT DA.
VM‑4HDT is a high-quality, long-reach HDBaseT extender and distributor that takes HDMI, IR
and RS-232 signals, and converts and distributes them to 4 HDBaseT outputs. The VM‑4HDT
supports HDMI resolutions up to 4K@60 (4:2:0), and the outputs can be connected to
compatible HDBaseT receivers such as the TP-580R.
VM‑3HDT and VM‑2HDT also include an HDMI LOOP output for connecting to an additional
unit in a daisy chain.
VM‑4HDT provides exceptional quality and advanced and user-friendly operation.
Exceptional Quality
• High Performance Distribution – Distributes one HDMI signal to four long-reach
HDBaseT extension outputs with up to 4K video resolution.
• Extension-line Distribution – Distributes a 4K@60Hz (4:2:0) 24bpp (maximum) video
signal over HDBaseT extension line to a distance of up to 40m (130ft) long-reach, and
even further for lower video resolutions.
• HDMI Signal Transmission – HDMI 2.0 and HDCP 1.4 compliant signal, supporting Deep
Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D. EDID
and CEC (OUT 1 only) signals are passed through from the source to the display.
For VM‑2HDT and VM‑3HDT, CEC is passed from the LOOP OUT to the HDBT
OUT 1 and to the display on the connected receiver.
