Step 4: Connect inputs and outputs
Always switch OFF the power on each device before connecting it to your VP-550X.
Condenser Microphone Pinout
Dynamic Microphone Pinout
For optimum range and performance use the recommended Kramer cables available at
www.kramerav.com/product/VP-550X.
Connecting the audio output
To a balanced stereo
audio acceptor:
To an unbalanced stereo
audio acceptor:
Step 5: Connect power
Connect the power cord to VP-550X and plug it into the mains electricity.
Safety Instructions (See www.kramerav.com for updated safety information)
Caution:
• For products with relay terminals and GPI\O ports, please refer to the permitted rating for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• Disconnect the power and unplug the unit from the wall before installing.
• Do not open the unit. High voltages can cause electrical shock! Servicing by qualified personnel only.
• To ensure continuous risk protection, replace fuses only according to the rating specified on the product label which located on the bottom of the unit.
