Table 1: VP-200XLT XGA Line Amp / CAT 5 Transmitter Features
# Feature Function
1 12V DC +12V DC connector for powering the unit
2 LINE OUT RJ-45 Connector
Connects to
1
the LINE IN RJ-45 connector on the TP-120 XGA Line
Receiver
2
or the VP-5R CAT 5 Receiver / 1:5 VGA/UXGA Distributor
3 XGA OUT 15-pin HD Connector Connect to the XGA acceptor
4 INPUT 15-pin HD Connector Connect to the XGA source
5 LEVEL Control knob Rotate to adjust the output signal level
6 EQ. Control knob Rotate to adjust the video EQ. (equalization) compensation
7 ON LED Illuminates when receiving power
5 VP-200XLTHD XGA Line Amp / CAT 5 Transmitter
The VP-200XLTHD
is a high-performance XGA line amp / CAT 5
transmitter that accepts one computer graphics (XGA) input, provides
necessary buffering and isolation, and distributes the signal to its high-
density 15 pin “D” connector output, as well as transmitting it over UTP
CAT 5 cable to its appropriate receiver. In particular, the VP-200XLTHD:
Can also receive HD signals (high-definition resolutions: 480p,
576p, 720p, 1080i and 1080p)
Has a transmission range of more than 300ft (more than 100m)
over UTP cabling
Has a video bandwidth exceeding 400MHz, ensuring transparency
even when operating at the highest resolutions
Includes output level control and cable equalization control, via
two trimmers on the side panel of the machine
Figure 2 and Table 2 define the VP-200XLTHD:
1 Using a UTP CAT 5 cable with RJ-45 connectors at both ends (the PINOUT is defined in Table 10 and Figure 13)
2 Refer to the separate user manual: PT-110, PT-120, TP-120, WP-110, which can be downloaded from the Internet at this
URL: http://www.kramerelectronics.com
