Technical Specifications
25
Table 13: Technical Specifications of the VP-300T (with 30m CAT 5 cable)
INPUTS: 1 XGA on an 15-pin HD connector
OUTPUTS: 2 XGA on 15-pin HD connectors
1 RJ-45 connector
MAX. OUTPUT LEVEL
1
:
1.9Vpp (XGA), 1.3Vpp (CAT 5)
BANDWIDTH (-3dB): 439MHz (XGA), 152MHz (CAT 5)
DIFF. GAIN
1
: 0.05% (XGA), 3.1% (CAT 5)
DIFF. PHASE
1
: 0.05Deg (XGA), 0.4Deg (CAT 5)
K-FACTOR
1
: <0.05% (XGA and CAT 5)
S/N RATIO
1
: 76dB (XGA), 71dB (CAT 5)
CONTROLS
1
: LEVEL: –8.9dB to 3.9dB (CAT 5)
EQ.: 0 to 30dB (CAT 5)
COUPLING
1
: DC (XGA), AC (CAT 5)
POWER SOURCE: 12 VDC 130mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98”) W, D, H
WEIGHT: 0.3kg (0.67lb) approx.
ACCESSORIES: Power supply
Table 14: Technical Specifications of the VP-5T/VP-5THD (with 60m CAT 5 cable)
INPUTS: 1 XGA on an 15-pin HD connector
OUTPUTS: 4 XGA on 15-pin HD connectors
1 RJ-45 connector
MAX. OUTPUT LEVEL
2
:
1.7Vpp (XGA), 1.7Vpp (CAT 5)
BANDWIDTH (-3dB): 445MHz (XGA), 154MHz (CAT 5)
RESOLUTION: Up to UXGA, up to 1080p
3
DIFF. GAIN
2
: 0.8% (XGA), 3.2% (CAT 5)
DIFF. PHASE
2
: 0.08Deg (XGA), 0.06Deg (CAT 5)
K-FACTOR
2
: 0.1% (XGA), <0.05% (CAT 5)
S/N RATIO
2
: 76dB (XGA), 73dB (CAT 5)
CONTROLS
2
: LEVEL: –7.4dB to 3.5dB (CAT 5)
EQ.: 0 to 37.8dB @50MHz (CAT 5)
COUPLING
2
: DC (XGA), AC (CAT 5)
POWER SOURCE: 230 VAC, 50/60 Hz. (115VAC, U.S.A.) 13VA
DIMENSIONS: 22cm x 18cm x 4.5cm (8.7” x 7” x 1.7”) W, D, H (half 19”, 1U)
WEIGHT: 1.2kg (2.6 lbs) approx.
ACCESSORIES: Power cord
1 For the VP-300T to TP-120 SETUP
2 For the VP-5T to TP-120 SETUP
3 The HD resolutions apply to the HD version of the machine
