Kramer VP-719xl

KRAMER: SIMPLE CREATIVE TECHNOLOGY
VP-724xl Communication Protocol
40
P
R
E
L
I
M
I
N
A
R
Y
Item Code Code(Hex)
~Code(Hex) Function Command
61 60 0x3C 0xC3 S-Video 2 L 3CC3
62 61 0x3D 0xC2 OUT L 3DC2
63 62 0x3E 0xC1 Blank L 3EC1
68 70 0x46 0xB9 Factory Reset L 46B9
69 71 0x47 0xB8 Key Lock L 47B8
70 72 0x48 0xB7 Wake up L 48B7
71 73 0x49 0xB6 Standby L 49B6
72 176 0xB0 0x4F PIP On L B04F
73 177 0xB1 0x4E PIP Off L B14E
74 178 0xB2 0x4D Freeze On L B24D
75 179 0xB3 0x4C Freeze Off L B34C
76 180 0xB4 0x4B Mute On L B44B
77 181 0xB5 0x4A Mute Off L B54A
78 182 0xB6 0x49 Blank On L B649
79 183 0xB7 0x48 Blank Off L B748
80 184 OxB8 0x47 Key Lock On L B847
81 185 0xB9 0x46 Key Lock Off L B946
82 186 0xBA 0x45 Output Resolution
L BA45 **
** is Resolution index
VP-719xl/VP-720xl VP-723xl/VP-724xl
640x480 L BA45 00
640x480 L BA45 00
800x600 L BA45 01
800x600 L BA45 01
1024x768 L BA45 02
1024x768 L BA45 02
1280x1024
L BA45 03
1280x1024 L BA45 03
1600x1200
L BA45 04
1600x1200 L BA45 04
852x1024i L BA45 05
852x1024i L BA45 05
1024x1024i
L BA45 06
1024x1024i L BA45 06
1366x768 L BA45 07
1366x768 L BA45 07
1365x1024
L BA45 08
1365x1024 L BA45 08
1280x720 L BA45 09
1280x720 L BA45 09
720x483 L BA45 10
720x483 L BA45 10
852x480 L BA45 11
852x480 L BA45 11
1400x1050
L BA45 12
1400x1050 L BA45 12
User Define
L BA45 13
480P L BA45 13
720P L BA45 14
1080i L BA45 15
User Define L BA45 16
81 227 0xE3 0x1C PIP Size L E31C **
** is PIP size index
