Kramer VS-44H2 Quick Start Guide

Step 6: Operate the VS-44H2
Operate via RS-232 and Ethernet communication parameters:
RS-232/Ethernet
Baud Rate:
115,200
Parity:
None
Data Bits:
8
Command Format:
ASCII Protocol 3000
Stop Bits:
1
Example (route video HDMI IN 4 to video HDMI OUT 1):
“#X-ROUTE
OUT.HDMI.1.VIDEO.1,IN.HDMI.4.VIDEO.1”,0x0D
Ethernet Parameters
IP Address:
192.168.1.39
Default TCP Port #:
5000
Subnet Mask:
255.255.0.0
Default UDP Port #:
50000
Default Gateway:
192.168.0.1
Username/Password:
Admin/Admin
Full Factory Reset
Front panel:
There is no option for factory reset from front panel.
Protocol 3000:
“#factory” command.
Web Pages:
Device Settings page, Soft Factory Reset resets all parameters to factory default except for network
parameters.
Operate via Front Panel Buttons
Switch an input to an output via front panel buttons
Press an output button followed by an input button to switch the selected input to the selected output.
Switch an input simultaneously to all 4 outputs
1. Press ALL. All 4 outputs on the 7-segment display flash.
2. Press an input button. The selected input is routed to all the outputs.
Store a switching setting
1. Configure the switching as required for the preset.
2. Press STO. The STO button flashes.
3. Press an input or output button (1-4). The input or output button flashes
and the STO button stops flashing.
Recall a switching setting
1. Press RCL. The RCL button flashes.
2. Press the relevant input or output button that stored the preset.
Once the stored preset is recalled, the RCL button stops flashing.
